Satellite Name: Eutelsat 3B (E3B)
Status: active
Position: 3° E (3° E)
NORAD: 39773
Cospar number: 2014-030A
Operator: Eutelsat Communications S.A.
Launch date: 27-May-2014
Launch site: Sea Launch (Odyssey platform)
Launch vehicle: Zenit 3SL
Launch mass (kg): 5967
Dry mass (kg):
Manufacturer: EADS Astrium
Model (bus): Eurostar-3000
Orbit: GEO
Expected lifetime: 15 yrs.
Call sign:
Beacon(s): 11200.2, 11699.8 RHCP or LHCP
Details:
51 C, Ku and Ka-band transponders to provide video, data, Internet and telecom services across Europe, Africa, the Middle East, Central Asia and parts of South America. A Ku-band payload of up to 30 transponders will be connected to widebeam footprints over extended Europe and East Africa. A steerable beam will add further flexibility, with coverage possible of South America or African regions. This capacity will address video contribution, corporate networks, data and telecom markets. A C-band payload with 12 transponders connected to a pan-African beam will respond to continued high demand for capacity for telecom services. A Ka-band payload of nine transponders connected to steerable beams that are in particular expected to cover Africa and South America will meet expanding connectivity requirements for corporate networks and Internet access.
Beams:Charts: list
Eutelsat 3B at 3° E downlink Ku-band Eastern beam coverage map
