Satellite Name: Anik G1
Status: active
Position: 107° W (107.3° W)
NORAD: 39127
Cospar number: 2013-014A
Operator: Telesat Canada Ltd.
Launch date: 15-Apr-2013
Launch site: Baikonur Cosmodrome
Launch vehicle: Proton M
Launch mass (kg): 4905
Dry mass (kg):
Manufacturer: Space Systems Loral (SSL)
Model (bus): LS-1300
Orbit: GEO
Expected lifetime: 15 yrs.
Call sign:
Beacon(s): 11701.75H, 11702.75H
Details:
16 transponders in extended Ku-band over Canada, 24 C-band and 12 Ku-band transponders over South America to provide direct-to-home and telecommunication services. First commercial military X-band payload (3 transponders) with coverage over the Americas and the Pacific Ocean including Hawaii. In-orbit testing at 109W orbital positions
Beams:Charts: list
Anik G1 at 107° W downlink X-band Global beam coverage map
